4N.2

Sr. No.	Image	Model	OEM Part No.	Description
1.		4N.2	311100-14	bearing bush violet Ø55 x Ø50 x 30 (31110014)
2.		4N.2	311100-17	bearing bush Ø50 x Ø45 x 40,7 (31110017)
3.		4N.2	305125-01	bearing cover (30512501)
4.		4N.2	302405-02	bottom plate steel 290 x 315 x 27 (30240502)
5.		4N.2	380306-32	Cheese Head Screw DIN 912, 10.9 M10 x 30 (38030632)
6.		4N.2	380402-07	cheese head screw DIN 84 M5 x 12 (38040207)
7.		4N.2	380507-51	cheese head screw 4.8 galvanized M4 x 8 (38050751)
8.		4N.2	383021-10	clamping sleeve DIN 7346 Ø8 x 18 (38302110)
9.		4N.2	382300-52	compression ring Piston diameter 59,96mm Ø60 x 1,5 (38230052)
10.		4N.2	302117-05	connecting rod Ø45 x Ø20 x 112 (30211705)
11.		4N.2	302297-24	connecting rod / piston (30229724)
12.		4N.2	343208-34	Crankcase Heater heating capacity: 100W 230V-1-50/60Hz (34320834)
13.		4N.2	301007-12	crankshaft Ø50 x 422 (30100712)
14.		4N.2	302360-01	cylinder head Water cooled (30236001)
15.		4N.2	302360-11	cylinder head air-cooled Air cooled 196 x 127 x 55 (30236011)
16.		4N.2	347320-33	differential oil pressure cut-out MP54 115V/230V-50/60Hz 100 x 50 x 130 (34732033)
17.		4N.2	389002-01	electric connector of the machine / device DIN 43650 Typ GDM 209 (38900201)
18.		4N.2	320314-01	fixing plate MP54 140 x 40 x 3 (32031401)
19.		4N.2	361110-01	gas equalising valve (36111001)
20.		4N.2	372704-01	Gasket discharge shut-off valve 91 x 52 x 1 (37270401)
21.		4N.2	372200-04	gasket teflon Ø38 x Ø35 x 1,5 (37220004)
22.		4N.2	372510-12	gasket Ø60, 127 x 196 x 0,9 (37251012)
23.		4N.2	372414-01	gasket 290 x 220 x 1 (37241401)
24.		4N.2	372611-01	gasket valve plate Capacity control 192 x 127 x 0,75 (37261101)
25.		4N.2	372312-01	gasket sealing cover Ø124 x Ø90,5 x 0,5 (37231201)
26.		4N.2	382501-04	gasket ring NBR felt ring G52 x 42 x 4 (38250104)
27.		4N.2	382403-05	Gasket Ring aluminium DIN 7603 A22 x 27 x 1,5 (38240305)
28.		4N.2	372810-02	gasket set (37281002)
29.		4N.2	372807-01	gasket set bearing cover Ø182 x Ø133 x 1/ 0,8/ 0,75 /0,6 /0,5 (37280701)
30.		4N.2	384102-03	gib-headed key start menu steel 12 x 8 x 46 (38410203)
31.		4N.2	345906-04	heater sleeve for 100W heater (34590604)
32.		4N.2	380056-07	hexagon head screw DIN 931, 10.9 M10 x 80 (38005607)
33.		4N.2	380035-01	hexagon head screw M6 x 40 (38003501)
34.		4N.2	380156-05	hexagon head screw DIN 933, 10.9 M10 x 25 (38015605)
35.		4N.2	380155-05	hexagon head screw DIN 933, 10.9 M8 x 20 (38015505)
36.		4N.2	380156-06	hexagon head screw coated DIN 933, 10.9 M10 x 30 (38015606)
37.		4N.2	380155-07	Hexagon head screw DIN 933, 10.9 M8 x 25 (38015507)
38.		4N.2	380154-06	hexagon head screw DIN 933, 10.9 M6 x 20 (38015406)
39.		4N.2	380339-01	Hexsocket Cheese Head Screw ISO 4762, 10.9 - A2K M10 x 30 (38033901)
40.		4N.2	300026-11	housing Ø60 (30002611)
41.		4N.2	386301-01	needle roller Ø3 x 8 / G2 (38630101)
42.		4N.2	372001-19	O-ring Ø74 x 2 (37200119)
43.		4N.2	372001-10	O-ring Ø39,69 x 3,53 (37200110)
44.		4N.2	372003-15	O-ring Ø36,3 x 1,78 (37200315)
45.		4N.2	372001-16	O-ring Ø50 x 3 (37200116)
46.		4N.2	362003-02	oil filter Ø14 x 105 (36200302)
47.		4N.2	361105-01	oil pressure relief valve (36110501)
48.		4N.2	361204-01	oil pressure relief valve (36120401)
49.		4N.2	362503-01	oil pump in view of grey cast iron (36250301)
50.		4N.2	382310-19	oil scraper ring Piston diameter 59,96mm Ø60 x 1,5 (38231019)
51.		4N.2	366000-06	pipe connection steel copper-plated brazed connection Ø28, 1 3/4" - 12 UN (36600006)
52.		4N.2	366000-07	pipe connection steel copper-plated brazed connection Ø35, 1 3/4" - 12 UN (36600007)
53.		4N.2	302232-16	piston aluminium alloy Ø55 (30223216)
54.		4N.2	325000-01	pressure spring steel Ø18 x 28 x 1,25 (32500001)
55.		4N.2	366201-19	Protective Cap Span of the jaw: 27 Plastic - GRP M24 x 2 / L=57,5 mm (36620119)
56.		4N.2	303312-11	pulley Taper-lock bush grey cast iron 3 x SPA x Ø230 x Ø50 (30331211)
57.		4N.2	382231-04	retaining ring with lugs spring steel DIN 472 Ø20 x 1 (38223104)
58.		4N.2	361500-01	Schrader valve T-piece brass Jul-16 (36150001)
59.		4N.2	366202-01	sealing nut 7/16" - 20 UNF (36620201)
60.		4N.2	366100-01	Sealing Plug brass 1/8" - 27 NPTF (36610001)
61.		4N.2	366110-10	sealing plug steel 1/2" - 14 NPTF (36611010)
62.		4N.2	380391-52	sealing plug 1" - 11 1/2" NPTF (38039152)
63.		4N.2	366110-02	Sealing Plug steel 1/4" - 18 NPTF (36611002)
64.		4N.2	366124-01	sealing screw permanent magnet M22 x 1,5 (36612401)
65.		4N.2	374011-11	shaft seal HFCKW (R22, R12, ...) (37401111)
66.		4N.2	374010-05	shaft seal NH3, HFC rotating part (37401005)
67.		4N.2	305416-05	shaft seal (30541605)
68.		4N.2	361310-08	shut-off valve brazing and welding bush Ø35 (1 3/8") (36131008)
69.		4N.2	361310-07	shut-off valve brazing and welding bush Ø28 (1 1/8") (36131007)
70.		4N.2	361802-02	sight glass Ø67 x 8,5 (36180202)
71.		4N.2	382201-51	single coil spring washer spring steel galvanized DIN 127 A4, 3 (38220151)
72.		4N.2	382141-02	single coil spring washer spring steel A6 (38214102)
73.		4N.2	362001-09	suction gas filter Ø30 x 105 (36200109)
74.		4N.2	312030-02	thrust collar Ø65 x 7 (31203002)
75.		4N.2	320500-07	thrust washer Ø62 x Ø48 x 1,7 (32050007)
76.		4N.2	320500-05	thrust washer Ø62 x Ø50,5 x 1,7 (32050005)
77.		4N.2	304052-04	valve plate Ø60 (30405204)
78.		4N.2	382002-01	washer brass DIN 125 A4, 3 (38200201)
79.		4N.2	383401-04	wrist pin Ø20 x Ø13 x 45 (38340104)
